Optimised for continuous use in industrial, commercial and agricultural applications

More variety: from 32 to 80 kWh energy content

Prismatic lithium-NMC cells (Samsung SDI)

Up to 98% battery efficiency

Your choice of energy management system (depending on requirements)

Ready for collective power plant usage

10-year system guarantee, 10-year performance guarantee

100% depth of discharge and 35% higher energy density

Compact design, reduced space requirements

Charging speed up to 1C

Extremely safe cell technology, certified by TÜV Rheinland

As a TESVOLT partner you will find all information about our products and offers in the Partner Portal. If you have any questions about this product or you are looking for an installer in your area - we are here for you!

Get in Touch Now!

The mature technical quality of our new TS HV 30-80 battery storage system is already evident in the impressive framework and modular structure. But for a truly intelligent storage solution you need to choose the right energy management system, one that’s precisely aligned with your specific requirements. For greater options, for true freedom.

For most standard applications such as self-consumption optimisation and peak shaving, the integrated SMA energy management system is all you need. For more demanding functions, greater control options and a much wider range of applications, you have the option of using the TESVOLT energy management system.

The energy management system is generally an integral component of the battery inverter. The SMA version for standard applications is already built in. With the TESVOLT energy management system you can choose from Basic or Pro versions – and there’s a system upgrade option if you change your mind later on. And with a much wider range of future-proof services, it’s a prudent investment in any case.

Self-Consumption Optimisation
Use more energy from renewable sources and minimise feed-in.

Physical Peak Shaving
Shave consumption peaks and minimise demand rate costs. The grid connection must be able to supply all loads.

Load Control
Consumption optimisation via active connection/disconnection of consumers depending on the energy generated.

Charging Station Control¹
Smart control of a single charge (set) point and central controls via the TESVOLT Energy Manager.

Generation Control
Consumption optimisation via active connection/disconnection of generators depending on the energy generated in grid operation.

Zero Feed-In
VDE FNN-certified fulfilment of grid requirements for not feeding electricity into the utility grid.

RLM Peak Shaving
A smart way of reducing consumption peaks at 15-minute intervals and making full use of storage systems.

Multi-Use
Simultaneous use of two applications (SCO & PS RLM, SCO & ToU, PS & ToU)

Charging Station Control¹
Smart control of multiple charge (set) points and central controls via the TESVOLT Energy Manager.

Time of Use
Time-dependent use of energy features and services.

Forecast-Based Charging
Depending on the weather forecast, curtailment losses from photovoltaic installations are avoided and self-consumption is optimised.

Dynamic Electricty Tariffs
The drawing of power from the grid can be automatically deferred to time windows with cheap electricity prices.

Self-Consumption Optimisation

RLM Peak Shaving

Physical Peak Shaving

Zero Feed-In

Generation Control

Ancillary Services

Direct Marketer Interface

1) Additional costs for project planing a incurred for more than one charging station

The Basic version is included in the battery storage system at no additional cost. It includes all the energy service functions listed below. These can be combined under restrictions.

1. Restriction: only if PV and battery inverter each perform one energy service feature.

2. Restriction: the customer can combine a maximum of two energy services.

3. Restriction: the customer can only combine predefined energy services .

The Pro version can be added to the battery storage system at an additional annual cost of EUR 3/kW (battery inverter output). It includes all of the energy service features listed below as well as the Basic version. These features can be combined and enable various energy service strategies to be used.

As a TESVOLT partner you benefit from the full range of digital services on our Partner Portal. With the service app, you have our support every step of the way: from project planning and design, configuration and ordering, right through to commissioning – any time, anywhere.

Go to the Partner Portal

Product name	TS HV 30 E	TS HV 50 E	TS HV 80 E
Type designation	TS HV 50/4-20	TS HV 50/5-20; TS HV 50/6-20; TS HV 50/7-20	TS HV 50/8-20; TS HV 50/9-20; TS HV 50/10-20
Energy content (at 100% DoD)	32 kWh	40 kWh / 48 kWh / 56 kWh	64 kWh / 72 kWh / 80 kWh
Nominal voltage	324 V ⎓	405 V ⎓ / 486 V ⎓ / 567 V ⎓	648 V ⎓ / 729 V ⎓ / 810 V ⎓
Operating voltage	290 - 365 V ⎓	363 - 457 V ⎓ / 436 - 548 V ⎓ 508 - 639 V ⎓	581 - 730 V ⎓ / 653 - 822 V ⎓ 726 - 913 V ⎓
Nominal/maximum charging/discharging current	100 A ⎓
Max. C-rate with STPS X 30	1C	0,7C/0,6C/0,5C	0,5C/0,4C/0,4C
Max. C-Rate withSTPS X 50	--	--/--/1C	0,8C/0,7C/0,6C
Overvoltage category	III
Cell	Lithium NMC prismatic (Samsung SDI)
Cell balancing	DynamiX Battery Optimizer
Cycles expected @ 100% DoD \| 70% SoH \| 23°C +/-5°C 1C/1C	6000
Cycles expected @ 100% DoD \| 70% SoH \| 23°C +/-5°C 0.5C/0.5C	8000
Efficiency (battery)	up to 98%
Self-consumption (standby)	5 W (without battery inverter)
Operating temperature	0°C to 50°C (derating at low temperatures)
Ambient temperature	0°C to 50°C (optimal: 25°C +/-5°C)
Ambient temperature for capacity guarantee	10°C to 45°C
Humidity	0 to 80% (non-condensing)
Cooling concept	Passive via fins and active via fans
Altitude of installation site	< 2,000 m above sea level
Max. noise emission (per fan running)	65 dB
Weight	346 kg	426 kg \| 482 kg \| 538 kg	615 kg \| 671 kg \| 727 kg
Gewicht Batteriemodul \| APU \| Schrank	56 kg \| 13 kg \| 107 kg	56 kg \| 13 kg \| 130 kg	56 kg \| 13 kg \| 150 kg
Dimensions of cabinet (H x W x D) with wall bracket	1208 mm x 608 mm x 808 mm 1208 mm x 608 mm x 990 mm	1608 mm x 608 mm x 808 mm 1608 mm x 608 mm x 990 mm	2008 mm x 608 mm x 808 mm 2008 mm x 608 mm x 990 mm
Tilt height of cabinet forwards, backwards/sidewards	1426 mm/1339 mm	1778 mm/1705 mm	2155 mm/2090 mm
Certificates/ standards Cell	IEC 62619:2017, UL 1642, UN 38.3
Certificates/ standards Battery module	UN 38.3, IEC 62619:2017, IEC 62620:2014
Certificates/ standards product	CE, UN 38.3, IEC 62619:2017, IEC 61010-1+A1:2016, IEC 61508:2010, IEC 61000-6-2:2016, IEC 61000-6-4:2019, IEC 61000-6-7:2015, 2006/66/EG (Battery Directive)
Guarantee	10-year performance guarantee, 10-year system guarantee
Recycling	TESVOLT offers a free take-back scheme for batteries from Germany
Protection class	IP 20
Degree of protection	I
Pollution degree	PD 2
IK class	IK 10
Battery specification as per IEC 62620:2014	INP46/175/127/[1P22S]M/-20+60/90

Type designation	STPS X 30	STPS X 50
Nominal power	30 kVA	50 kVA
AC voltage range	340 V bis 477 V
Grid frequency range	44 Hz bis 66 Hz
DC voltage range	200 V ⎓ to 980 V ⎓
Dimensions (H x W x D)	837.3 mm × 772 mm × 443.8 mm
Max. efficiency/European efficiency	98%/97.6%	98%/97.2%
Self-consumption (standby)	25 W
Operating temperature	-25 to 60°C (with derating)
Noise emission (typical)	69 dB (A)
Weight	104 kg
Protection class	IP 65 \| NEMA 4X
Communication	Modbus (SMA, Sunspec), SMA Speedwire, Webconnect
Topology/cooling principle	Three-phase/active
Guarantee	5 years standard SMA guarantee (optional: 10 years)
Certificates	see SMA website for more: https://www.sma.de

1. Battery storage system

In the system design, the battery storage system is a key component for storing surplus electrical energy, enabling load compensation, ensuring security of supply and contributing to cost reduction and the integration of renewable energy.

2. Inverter

The combination of battery storage system and inverter ensures efficient power supply through a flexible conversion of direct and alternating current coupled with direct response to grid fluctuations.

3. Energy management system

The EMS optimises energy flow and controls the charging and discharging of the battery storage system and all consumers and energy sources to enable a wide range of applications.

4. Energy resources

The wide range of energy sources in the system design, such as photovoltaics or wind power, generate the required electricity, which the battery storage system stores without environmental impact.

5. Utility grid

The grid acts as an additional back-up resource in the system for periods when renewable energy is insufficient. In combination with a battery storage system, it actively relieves the strain on the public utility grid and provides a reliable supply of electricity, particularly at peak load times.

6. Portal

The portal allows users to monitor energy flows, track the system status and analyse energy consumers to efficiently and transparently manage the energy balance and to ensure customised energy supply.

7. Consumers

Efficient energy supply enables tailoring to the energy needs of consumers, resulting in the sustainable and cost-effective use of renewable energy.

Installation manuals, certificates and manufacturer's declarations for the complete E-series can now be found in the protected area of our partner portal:

Click here to log in or register: PARTNER PORTAL

Product Brochure TS HV 30-80 E

Datasheet TS HV 30-80 E

Small Commercial Solutions Brochure

Commercial Solutions Brochure

More Downloads

The TS HV 30-80 E is a 32 kWh to 80 kWh battery storage system with 30 kW or 50 kW battery inverter and can be scaled variably. Using your storage system for standard applications like self-consumption optimization and peak shaving, controlling your charging stations, or using different applications in parallel with the multi-use function – the TS HV 30-80 E is the battery storage system for every usage. With back-up operation pending, in the future the system will also be able to provide reliable power in the case of grid outages.
Complete battery storage package consisting of a cabinet with 4 to 10 battery storage modules including APU and DynamiX Battery Optimizer, a cable set to the inverter, battery inverter and energy meter (Janitza Energy Meter). Choice between TESVOLT energy management incl. myTESWORLD or SMA energy management powered by ennexOS.

## General battery data ##

# Battery Module 8.0-1C-HV1500 #
Module energy: 8,0 kWh
Cells: Lithium-NMC prismatic (Samsung SDI)
Dimensions: 160 x 370 x 648 mm mm (H x W x D)
Weight per module: 56 kg
DynamiX Battery Optimizer (DBO) Technology by TESVOLT with active cooling

# Active Power Unit (APU) #
Central power and control unit of the battery system
Interface to the battery inverter
Communication: ModBus TCP / IP
Self-consumption (Stand-by): 5 W
Weight: ca. 13 kg

# Battery storage system in general #
Max C-rate: 1C
Depth of Discharge: 100 % DoD
Round Trip Efficiency (battery): up to 98 %
Expected cycles @ 100 % DoD | 70 % SoH | 23 °C +/- 5 °C | 1C/1C: 6.000
Expected cycles @ 100 % DoD | 70 % SoH | 23 °C +/- 5 °C | 0,5C/0,5C: 8.000
Operating temperature range: 0 °C to 50 °C (with derating at low temperatures)
Ambient temperature range: 0 °C to 50 °C (recommended: 25°C +/- 5°C)
Humidity: 0 % to 80 % (non-condensing)
Protection class: IP 20
Certificates: UN 38.3, IEC 62619, IEC 62620, IEC 61010-1, IEC 61508, IEC 61000-6-2/4/7
Expandability: Maximum 4 battery storage systems per inverter
10-year battery Performance Warranty
10-year System Warranty


[__] piece(s) ## Battery storage TS HV 30 E ##
Battery cabinet with 4 battery modules and one APU
Energy content: 32 kWh
Operating voltage range: 290 to 365 VDC
Dimensions: 1208 x 608 x 990 mm (H x W x D), tilt dimension: 1426 mm
Empty weight: 107 kg / total weight (approx.): 346 kg
Can be used with STPS X 30


[__] piece(s) ## Battery storage TS HV 50 E ##
Battery cabinet with 5 / 6 / 7 battery modules and one APU
Energy content: 40 kWh / 48 kWh / 56 kWh
Operating voltage range: 363 to 457 VDC / 436 to 548 VDC / 508 to 639 VDC
Dimensions: 1608 x 608 x 990 mm (H x W x D), tilt dimension: 1778 mm
Empty weight: 130 kg / total weight (approx.): 426 / 482 / 538 kg
Can be used with STPS X 30 and STPS X 50 (only with 7 battery modules)


[__] piece(s) ## Battery storage TS HV 80 E ##
Battery cabinet with 8 / 9 / 10 battery modules and one APU
Energy content: 64 kWh / 72 kWh / 80 kWh
Operating voltage range: 581 - 730 VDC / 653 - 822 VDC  / 726 - 913 VDC
Dimensions: 2008 x 608 x 990 mm (H x W x D), tilt dimension: 2155 mm
Empty weight: 150 kg / total weight (approx.): 727 kg
Can be used with STPS X 30 and STPS X 50


[__] piece(s) ## Battery inverter SMA STPS X 30 ##
Rated power: 30 kVA
DC voltage range: 200 VDC to 980 VDC
Rated AC voltage: 400 V, 50/60 Hz
Max. efficiency / European efficiency: 98.0 % / 97.6 %
Topology: without transformer
Operating temperature range: -25 °C to 60 °C (with derating)
Dimensions: 837.3 x 772 x 443.8 mm (H x W x D)
Weight: 104 kg
Protection class: IP65 / NEMA 4X


[__] piece(s) ## Battery inverter SMA STPS X 50 ##
Rated power: 50 kVA
DC voltage range: 200 VDC to 980 VDC
Rated AC voltage: 400 V, 50/60 Hz
Max. efficiency/European efficiency: 98.0 % / 97.2 %
Topology: without transformer
Operating temperature range: -25 °C to 60 °C (with derating)
Dimensions: 837.3 x 772 x 443.8 mm (H x W x D)
Weight: 104 kg
Protection class: IP65 / NEMA 4X
